Utility
Mechanical (Piping)
Constraints
Edge loop centered
Angle
Graphics
Size on screen
Mechanical
Fixture Units
K Coefficient
Flow Factor
Flow
Pressure Drop
Flow Configuration
Flow Direction
Loss Method
Allow Slope Adjustments
System Type
K Coefficient Table
Dimensions
Radius
Identity Data
Index
442 | Chapter 9 Revit Families
Indicates whether the connector is exported on a site utility to an Autodesk Exchange
file (ADSK). See Importing Building Components
Connector placement method (read only).
Used for adjustable angle families (such as elbows and adjustable tees) to push the
angle value into the family from connected components.
Size of the connector display inside the Family Editor.
Active only when the System Type is Sanitary, Domestic Hot Water, or Domestic Cold
Water and the Flow Configuration is Fixture Units.
K Coefficient (K Factor) is only editable if Loss Method is specified as "K Coefficient".
Percentage of the system flow attributed to this connector. Active only when the Flow
Configuration is System.
Volumetric flow rate of fluid through connector.
Active only when the Loss Method is Specific Loss
Possible values are: Calculated, Preset, System.
Possible values are: In, Out, Bidirectional. Bidirectional is active only when the Flow
Configuration is Calculated.
Possible values are: Not Defined, K Coefficient from Table, K Coefficient, Specific Loss.
Possible values are: Checked or unchecked.
Possible values are: Undefined, Hydronic Supply, Hydronic Return, Sanitary, Domestic
Cold Water, Domestic Hot Water, Fire Protection, Other.
Possible values are: Bell Mouth Inlet or Reducer, Inward Projecting Pipe, Outlet, Square
Edged Inlet. Active only when the Loss Method is K Coefficient from Table.
The nominal size of the connector.
A unique identifier for a connector in a family (read only).
on page 1398.
