Entering Search Text

When searching for materials or render appearances, you can enter search text in the box of the dialog.
The search is not case-sensitive. Use commas, spaces, or semi-colons as delimiters. Revit Architecture
automatically performs an OR search on multiple words.
Revit Architecture searches each item for the specified text, checking its description and keywords. If you
selected a class, Revit Architecture searches only items in that class for the specified text.
The dialog displays matching items, sorted in order of relevance. Items that match all of the search words
display at the top of the list. Items that match fewer search words display near the bottom of the list.
TIP To clear the search field, click the X that displays at the end of the field after you enter text.
Related topics
Searching for a Render Appearance
Searching for a Material

Object Styles

The Object Styles tool specifies line weights, line colors, line patterns, and materials for different categories
and subcategories of model objects, annotation objects, and imported objects in a project.
You can override project object styles on a view-by-view basis. For more information, see
Graphic Display in Project Views

Creating Object Style Subcategories

1 Click Manage tab
2 Click the Model Objects, Annotation Objects, or Imported Objects tab.
3 In the Object Styles dialog under Modify Subcategories, click New.
4 In the New Subcategory dialog, enter a name.
5 Select the Category for Subcategory of.
6 Click OK.

Modifying Object Styles

1 Click Manage tab
2 Click the Model Objects, Annotation Objects, or Imported Objects tab.
3 Specify the projection, and, if applicable, cut line weights for the category.
4 Click the color value to set the line color.
5 Select a line pattern.
on page 470
on page 198.
Project Settings panel
Project Settings panel
This enables you to control the display of geometry when it is cut and not cut without having
to create separate subcategories. For imported geometry layers, specify the appropriate line
weight.
on page 491
Settings drop-down
Settings drop-down
Visibility and
Object Styles.
Object Styles.
Entering Search Text | 493
