Creating a Callout View

Detailing
Cutting a Plan View by the Back Clip Plane
Cutting an Elevation, Section, or Callout View by the Far Clip Plane
View callouts
Use a view callout when you want to provide more or different information about a part of the parent view.
For example, you can use a view callout to provide a more detailed layout of fixtures in a bathroom.
When you add a view callout to a view, Revit Architecture creates a view that has the same view type as the
parent view. For example, if you add a callout tag to a floor plan view, the callout view is also a floor plan
view, and displays in the Project Browser under Views (all)
A view callout offers the same capabilities as its parent view. For example, you can specify another view to
use as an underlay, assign a color scheme, and specify a view range. Use properties of the callout view to
specify these parameters.
See Creating a Callout View

Callouts and Sheets

Callouts are tools for making coherent document sets. They are designed to send the user (builder, contractor,
installer) from one view to another. Plan your use of views and callouts to provide a logical sequence that
moves the user from large-scale plans to views with greater levels of detail.
You can place callouts on the same sheet as the parent view, or place details on sheets by category (for
example, roof eave details, or window sill details). You can use standard details in drafting views as references
for multiple callouts that detail the same condition.
Creating a Callout View
You can add a detail callout or a view callout to a plan, section, detail, or elevation view. (See
on page 147.) When you draw the callout bubble in a view, Revit Architecture creates a callout view. You can
then add details to the callout view to provide more information about that part of the building model.
NOTE To create a reference callout, see
1 In a project, click View tab
2 Click Callout tab
3 On the Options Bar, for Scale, select a scale for the callout view.
4 To define the callout area, drag the cursor from the upper-left to the lower-right, creating a
148 | Chapter 5 Project Views
on page 148
on page 1134
on page 148.
Element panel, and from the Type Selector, select the type of callout to
create: a detail callout or a view callout (a callout view that has the same view type as the parent
view).
See Callout Types on page 147.
callout bubble as shown by the dashed line enclosing the upper-left corner of the grid.
on page 127
Floor Plans.
Creating a Reference Callout
Create panel Callout.
on page 133
on page 154.
Callout Types
