Removing the LBX Terminator Board
There are three versions of the LBX board (card) and two versions the LBX
Note
terminator board (card). For more information, see
and
1
Unscrew the thumbscrew and remove the LBX/IEX cover plate from the control module or last
expansion module in the existing configuration.
LBX/IEX cover
plate thumbscrew
2
Remove the LBX terminator from the J17 and J2 connections on the LBX board.
Determine your library configuration and verify what version of LBX terminator is needed.
3
There are two versions of the LBX terminator board (card). For more information, see
on page 349.
LBX terminator
Scalar i6000 Installation Guide
LBX Terminator
on page 349.
J17 connection
LBX Board
on page 345
LBX Terminator
85
