Installing Expansion Modules after Installing the System Unit

Only use the following procedures if you are adding expansion modules to a newly installed system unit (a
system unit consists of four or less frames). For more information on system units, see
and Expansion Modules as System Units

Positioning the New Expansion Module

The first steps in adding a new expansion module to a system unit involve locating and positioning the
expansion module. For more information on location specifications, see the Scalar i6000 Planning Guide.
A label placed on the floor in the rear of the expansion module shows the order
Note
in which to place the module.
Required tools: none
1 Position the expansion module next to the last module in the system unit.
2 Verify the following:
• There is adequate clearance for the access and service doors.
• All raised floor tiles have been cut out accordingly to accommodate the power, SCSI, Fibre, and
Ethernet cables to any of the modules.
3 Verify that the expansion module is positioned correctly.
4 Ensure that the leveling legs are not resting on tiles that will need to be raised to accommodate cables
after the expansion module has been installed.

Lowering the Leveling Legs

Required tools: 24 mm open end wrench, 6 mm hex wrench or 16 mm open end wrench.
1 Use the 24 mm open end wrench to loosen the four locking nuts on the four corner legs.
CAUTION
2 Lower the legs by hand until the pads touch the floor. You may need to use either a 6 mm hex wrench
or 16 mm open end wrench to turn the legs if the threads do not turn freely.
To ensure even weight distribution on the legs, it is very important that all
Note
legs be brought into contact with the floor without lifting the module.
You can verify whether a leg is in contact with the floor by attempting to
slide a piece of paper underneath it.
Scalar i6000 Installation Guide
on page 28.
If you do not loosen the locking nuts, you may strip the threads on the
leveling legs during movement.
