Aligning the Middle X-Axis Channel

If you are installing a new library, go to
You only need to perform this procedure on expansion modules being added to
Note
the system unit. Complete systems ship from the factory with the middle X-axis
channel already aligned.
If you are adding one or more expansion modules to a system unit, do the following:
1 With the middle X-axis rail completely loose, do the following:
a. Place the centering tool over screw 3 and into the counterbore of the X-axis rail.
b. Holding the centering tool in place, tighten screw 3.
c. Repeat for screw 8.
junction
middle X-axis rails
Scalar i6000 Installation Guide
Aligning the Middle X-Axis Rail
1 2 3 4
x-axis channels
on page 46.
counterbore
in middle X-axis rail
3 mm screw
5 6 7 8 9 10
45
