16 Use a #2 Phillips screwdriver to replace the top drive cluster cover plate, the mid-module cover plate,
the bottom drive cluster cover plate, and the LBX/IEX cover plate.
top drive cluster
cover plate
LBX/IEX cover plate
286
mid-module cover plate
bottom drive cluster
cover plate
Adding Optional Hardware
