Ethernet Expansion Blade LEDs

The status LEDs for an Ethernet Expansion blade are located at the top of the EEB above ETH 6.
45 shows the locations of the I/O blade Fibre port link LEDs.

Figure 45Location and Colors of Ethernet Expansion Blade Status LEDs

EEB LED status
Port LED status
Table 24 Explanations of Ethernet Expansion Blade LED States
Blue Green
Off Off
1 Hz Off
Off Off
Flash 1 Hz
Flash 10 Hz
Table 25 Explanations of EEB Ethernet Port LED States
LED Color Possible States and Explanations
Green • Solid on — the link is up; data can be sent or received through the Ethernet port
• Solid off — the link is not up; data cannot be sent or received through the Ethernet port
Amber • Flashes at irregular intervals — data activity is occurring through the Ethernet port
• Solid off — no data activity is occurring through the Ethernet port
Scalar i6000 Installation Guide
Amber Description
Off No power
Off Powered Down - Ready for removal
On Booting
Off Normal
Off Normal - Identify
