7 Use your thumbs on each end of the blade to evenly apply pressure and slide it into the I/O management
unit. When you feel the pins of the CMB lock into the backplane, push the latchhooks towards the middle
of the blade and into the lock position.
CAUTION
8 Detach the ESD strap and close the door.

Installing an FC I/O Blade

Required tools: ESD strap
1 Open the service door of the module.
2 Attach the ESD strap to your wrist and to an unpainted surface inside the door.
3 Remove the cover plate from bay where the FC I/O blade will be installed. The population order for the
FC I/O blades is shown below.
Make sure you install the FC I/O blade into the correct bay.
Note
cooling assembly
4 Remove the FC I/O blade from the protective anti-static bag.
5 Press up and out to open the latchhooks on each side of the FC I/O blade.
260
Slots that are not populated with blades must contain a cover plate. If
the cover plates are not installed, FC I/O blade temperature errors will
occur.
Adding Optional Hardware
