10 Use the 7 mm nut driver to secure the four retaining screws.
7 mm screws
11 Through the space behind the LBX board, connect the W17 cable to the J48AP connection on top of
the power chassis. This is the connection to the power distribution unit.
Scalar i2000 Installation Guide
connector:J48AP
plug: W17 to I/O management unit
249
