2 Remove the nine (9) 2.5 mm screws that attach the right side panel to the module.
Three screws are located at the front corner post, three at the back corner post,
Note
and three at the storage wall.
2.5 mm screw
front of module
2.5 mm screw
2.5 mm screw
76
2.5 mm screws
back of module
2.5 mm screws
2.5 mm screws
