7
Use a #2 Phillips screwdriver to remove the top drive cluster cover plate, the mid-module cover plate,
the bottom drive cluster cover plate, and the LBX/IEX cover plate.
top drive cluster
cover plate
LBX/IEX cover plate
8
Identify which version of the IEX card is currently installed in the library, If the library contains an IEX2
card (identified by a red sticker), skip to
283.
282
bottom drive cluster
cover plate
Step 12
on page 284. Otherwise, proceed to
mid-module cover plate
Step 9
Adding Optional Hardware
on page
