Quantum Scalar i6000 Installation Manual page 134

7 Route the cable through the cable keepers and down the right side of the control module or expansion
module.
8 Insert the EEB cable into the EEB port connection on the drive.
EEB cable connected
to drive coordinate 1,1,1,1,1,1
9 Repeat Step 5 on page 121 through
connected to an EEB.
The EEB port and drive numbers will change according to
Note
119.
122
Step 8 on page 122 for each drive that will be installed and
EEB cable routed
through cable
keepers
Table 6 on page
Cabling
