6 Connect the W2 Ethernet cable to the J3 connection on the LBX board on the control module or last
expansion module in the existing configuration.
This connects the J4 connection on the LBX board in the new expansion module to the J3 connection
on the LBX board in the control module or last expansion module in the existing configuration.
The LBX board has three versions and the LBX terminator has two
Note
versions. For more information, see
Terminator
LBX board on
expansion module
J2
J17
7 Determine the LBX terminator installation:
• Determine your library configuration and verify what style of terminator is needed. There are two
versions of the LBX terminator board (card). For more information, see
349.
• Once you have determined what style of terminator you need, install it into the J17 connection on
the LBX board in the last expansion module.
LBX terminator
68
on page 349.
W1 cable
(large ribbon cable)
J1
J4
W2 cable (Ethernet)
J17 connection
LBX Board on page 345 and
LBX board on
control module or
expansion module
J2
J3
LBX Terminator
Installing a Multi-Module Library
LBX
J1
on page
