LBX Terminator Version 03 LEDs

The LBX terminator version 03 has six green LEDs that indicate the presence of modules in the library.
Figure 49 shows the locations of the LEDs.
terminator.
Figure 49 Locations of LBX Terminator LEDs (Version 03)
1
Table 28 Explanations of LBX Terminator LED States (Version 03)
LED On/Off Combinations
1 2 3 4
Off Off Off Off
On Off Off Off
On Off Off On
On Off Off On
On Off Off On
On Off Off Off
On Off Off On
On Off Off Off
On Off Off Off
On On Off Off
On On Off On
On On Off On
On On Off On
Scalar i6000 Installation Guide
Table 28
2 3 4 5
5 6
Off Off Robotics are disabled, the access door is open, or the LBX
terminator is misaligned.
Off Off The library has one control module and no expansion modules.
Off Off The library has one control module and one expansion module.
On Off The library has one control module and two expansion modules.
On On The library has one control module and three expansion modules.
On On The library has one control module and four expansion modules.
Off On The library has one control module and five expansion modules.
On Off The library has one control module and six expansion modules.
Off On The library has one control module and seven expansion modules.
Off Off The library has one control module and eight expansion modules.
Off Off The library has one control module and nine expansion modules.
On Off The library has one control module and ten expansion modules.
On On The library has one control module and eleven expansion modules.
describes how to interpret LED activity on the LBX
6
Explanation
363
