7 Route the cable into the P-clamp.
aisle light cable
8 Plug the aisle light cable into the aisle light assembly connector.
9 Install the P-clamp to the bolt and partially tighten the nut.
aisle light assembly
connector
bolt
10 Pull any excess aisle light cable through the P-clamp towards the front of library.
11 Completely tighten the P-clamp nut.
12 Run the aisle light cable along top panel of the frame, routing it with any cables that exist, and feed the
cable through the rear access hole to the back side of the library.
300
P-clamp
nut
rear access hole
