Adding a 24-Slot I/E Station to an Expansion Module

This section describes how to upgrade an expansion module to include a 24-slot I/E station.
You can add 24-slot I/E stations to the control module and any of the first seven
Note
expansion modules.
Required tools: #2 Phillips screwdriver, 2.5 mm hex wrench, disposable screw capture tool, wire cutters (for
plastic ties), ESD strap
1 You must export all media from the access door being upgraded.
a. Log into the Library Management Console (LMC).
b. Click Operations → Export.
2 Before removing any magazines in the access door of the expansion module you are upgrading,
determine if the magazines are used in any partitions.
3 If the Automatic Teach mode is being used, disable it to perform this upgrade procedure.
4 Remove the magazines in the access door from each partition(s) using the following procedure:
a. Click Physical on the View menu.
b. Click Setup→ Partitions→ Configure.
The Partitions dialog box is displayed.
c. Select the partition that include the affected magazines and click Modify.
d. Return the affected magazines to the physical pool.
e. Repeat Steps a through d for each partition associated with the access door you are upgrading.
5 Shut down the library.
For more information, see
Scalar i2000 Installation Guide
Shutting Down the Library on page 232.
