4
Plug the IEX board into the new LBX board.
5
Use your thumb to snap the IEX board onto the two standoffs.
standoffs
6
Replace the LBX/IEX cover plate and tighten the thumbscrew.
7
Detach the ESD strap and close the door.
Scalar i6000 Installation Guide
thumbscrew
IEX board
91
