The following procedure provides instructions for adding drives to an existing library. See
on page 105 for installing drives in a new library.
Required tools: 2.5 mm hex wrench, #2 Phillips screwdriver, ESD strap
7 Determine which magazines must be removed in order to add a drive and determine if the magazines
are used in any partitions.
8 Remove the magazines from each partition(s) using the following procedure:
All partition elements associated to this upgrade procedure must be
CAUTION
modified before proceeding with this procedure.
Prior to modifying any partitions, you must understand your
configuration changes and the potentially disruptive effects those
changes can have on the host application(s).
Care must be taken whenever you add or delete partition elements,
which includes drives, storage magazines, and I/E station magazines.
a. Click Physical on the View menu.
b. Click Setup→ Partitions→ Configure.
The Partitions dialog box is displayed.
c. Select the partition that include the affected magazines and click Modify.
d. Return the affected magazines to the physical pool.
e. Repeat Steps a through d for each partition associated with the drive installation procedure.
9 On the operator panel, press the Robotics Enabled button to return the accessor assembly to the
home position.
The power remains on for all other components.
10 Open the access door.
11 Remove the magazines in front of the lowermost vacant drive location to make room for the drive. To
remove, push the magazine upward with both hands until it unsnaps, and then pull the magazine toward
you.
