5 From inside the expansion module, use a 2.5 mm hex wrench to install the nine (9) screws that attach
the side panel to the module.
2.5 mm screw
front of module
2.5 mm screw
2.5 mm screw
6 Reinstall the removed magazines removed in
7 Reattach all of the service doors.
8 Repeat steps Step 1
9 Once the components are installed, if applicable, perform the procedures detailed in
and Blades on page 97.
Scalar i6000 Installation Guide
on page 70 through Step 3
Step 1 on page 70.
on page 71 on each expansion module.
2.5 mm screws
back of module
2.5 mm screws
2.5 mm screws
