12 Use a 2.5 mm hex wrench to attach the I/E station to the door using the six screws removed in
on page 271.
13 Use a #2 Phillips screwdriver to mount the new expansion module skin onto the upper area of the
access door next to the I/E station using three screws.
Scalar i2000 Installation Guide
2.5 mm screws
three #2
Phillips screws
Step 8
273
