9 Use the 2.5 mm hex wrench to remove the six screws that hold the top-right magazine filler panel to the
inside of the access door.
10 Remove the filler panel. Set the screws aside.
11 From the inside of the access door, mount the I/E station by first inserting the top of the I/E station over
the top rim flange of the door's I/E station opening. Once the top is in place, the I/E station should hang
in the opening with the screw holes cut in the sides of the I/E station lining up with the holes in the door.
272
magazine filler panel
2.5 mm hex screws
Adding Optional Hardware
