5
Slide the I/O management unit cooling assembly into the top slot of the I/O management unit until fully
seated.
cooling assembly
latch handle
6
Push the latch handle into the up position.
7
Use a #1 Phillips screwdriver to tighten the thumbscrew on the I/O management unit cooling assembly.
258
Phillips screw
I/O management unit
Adding Optional Hardware
