❑ Verify all FC I/O blade port configurations. Click Setup→ Connectivity→ Port Configuration. Select
each installed FC I/O blade and one of the 6 ports. All FC I/O blades have the same port settings, as shown
in Table 15 .
Table 15 FC I/O Blade Default Port Settings
Port Loop ID
FC-1 Soft
FC-2 Soft
FC-3 Soft
FC-4 Soft
FC-5 Soft
FC-6 Soft
❑ Verify that the physical library and all partitions are online.
• In the LMC, click Operations→ Change Mode and verify that Online is selected. Repeat this for
each partition that was created.
❑ Verify Host Type Settings.
• In the LMC, click Setup→ Device Access→ FC host and then click Host Type to verify the values.
❑ Verify all Host LUN Mapping.
• In the LMC, click Setup→ Device→ Access→ FC Host, and then click LUN Mapping to verify the
values.
❑ Verify proper switch zoning, if one or more are connected to the library.
❑ Verify the host bus adapter (HBA) configuration and port settings on the host(s).
❑ Verify that the Media Changer and Devices appear in the device list for each host.
❑ Save the library's configuration file onto a remote computer running the remote LMC client.
Scalar i6000 Installation Guide
Speed Frame Size
Auto 2048
Auto 2048
Auto 2048
Auto 2048
Auto 2048
Auto 2048
Connection
Port Mode
Option
Target Loop preferred
Target Loop preferred
Initiator Loop preferred
Initiator Loop preferred
Initiator Loop preferred
Initiator Loop preferred
Private/Public
Public
Public
Public
Public
Public
Public
