I/O Management Unit Bay Numbering Sequence
Figure 10
shows the numbering sequence and the bay positions in the I/O management unit.
Bay 2 is reserved for the control management blade (CMB). Bay 1 is not used.
Note
Figure 10
I/O Management Unit Bay Layout
cooling assembly
104
Installing Drives and Blades
