LBX Terminator

For information on the LBX board, see
terminator LEDs, see Interpreting LBX Terminator LEDs
• Any LBX board version LBX2 Gen 1 located in the last module in the library
Note
must be terminated using LBX terminator version 01 shown in
• Any LBX board version LBX2 Gen 2 located in the last module in the library
must be terminated using LBX terminator version 03 shown in
• Any LBX board version LBX2 Gen 3 located in the last module in the library
must be terminated using LBX terminator version 03 shown in
Figure 39 Comparison of LBX Terminator Versions
Version 01
Figure 40 LBX Board and Terminator Installed
Scalar i6000 Installation Guide
LBX Board on page 345. For information on interpreting the LBX
LBX terminator
LBX board
on page 362
Version 03
Figure 39.
Figure 39.
Figure 39
349
