52 Install the supplied magazines into each of the I/E stations.
53 Using a 3 mm hex wrench to reinstall the access door latches of the expansion module to the right of
the new access door. Make certain the latches are positioned correctly.
Top two
latches have
rollers pointing
down
bottom 2 latches
have rollers pointing
up
Scalar i2000 Installation Guide
I/E station magazines
storage
295
