Figure 17 shows the section, column and row numbering for rack 1 of a module with LTO cartridges. See
Figure 16 on 132 to review the rack numbering.
Figure 17 Section, Column, and Row Numbering Locations for Rack 1 Using LTO Cartridges
1 1
1 1
2 2
3 3
4 4
5 5
7 7
8 8
9 9
10 10
When tape drives are installed on rack 1 of a control module or expansion
Note
module, they replace the storage in columns 1 and 2. Because drives are
installed from the bottom to the top you will lose the storage starting in section
10 first. You do not lose the magazine in column 2 of section 5.
Column 1 does not contain storage in the control module.
Scalar i6000 Installation Guide
column
2 2 3 3 4 4
row (individual slot)
1 1 1
2 2 2
3 3 3
4 4 4
5 5 5
6 6 6
X-axis rail counts as Section 6
