Installing an Ethernet Expansion Blade
Required tools: ESD strap
1
Open the service door of the module.
2
Attach the ESD strap to your wrist and to an unpainted surface inside the door.
3
Remove the cover plate from bay where the Ethernet Expansion blade will be installed. The population
order for the Ethernet Expansion blades is shown below.
Make sure you install the EEB into the correct bay.
Note
cooling assembly
4
Remove the Ethernet Expansion blade from the protective anti-static bag.
5
Press up and out to open the latchhooks on each side of the Ethernet Expansion blade.
