This appendix describes the LBX board and terminator.

LBX Board

A module may contain one of three versions of the LBX board shown in
For information on the LBX terminator, see
• Library configurations of four modules or fewer may contain LBX2 Gen 1 or Gen 2 boards.
• Library configurations of five to eight modules must contain LBX2 Gen 2 boards.
• Library configurations of nine to twelve modules:
• Modules one through seven must contain LBX2 Gen 2
• Modules eight through twelve must contain LBX2 Gen 3
• If you are adding one or more expansion modules to an existing eight-module library, and the LBX
board is an earlier version, you must remove the LBX board from expansion module seven (position
eight) and replace it with the new version, LBX2 Gen 3.
For instructions on removing and replacing the LBX board and terminator, see the Scalar i2000/i6000
Maintenance Manual.
Red stickers identify the LBX2 Gen 3 board required in the expansion
Note
modules added to a library configuration greater than eight modules.
Scalar i6000 Installation Guide
LBX Board and Terminator
LBX Terminator on page 349.
