Table 5 shows which FC I/O blades must be connected to the FC drive in each of the 12 drive coordinates
in either a control module or expansion module. For information on the library's coordinate system, see
Storage Addressing System Overview
Table 5 Cable Connection Requirements for FC Drives
FC I/O Blade Positions in the
I/O Management Unit
Bay 3
Bay 3
Bay 3
Bay 3
Bay 4
Bay 4
Bay 4
Bay 4
Bay 5
Bay 5
Bay 5
Bay 5
114
on page 132.
FC Connection on I/O Blade
FC-3
FC-4
FC-5
FC-6
FC-3
FC-4
FC-5
FC-6
FC-3
FC-4
FC-5
FC-6
Drive Coordinates
1,1,1,1,1,1
1,1,1,2,1,1
1,1,1,3,1,1
1,1,1,4,1,1
1,1,1,5,1,1
1,1,1,6,1,1
1,1,1,7,1,1
1,1,1,8,1,1
1,1,1,9,1,1
1,1,1,10,1,1
1,1,1,11,1,1
1,1,1,12,1,1
Cabling
