Interpreting Drive Status LEDs

The library reports all drive issues that can affect customer operations. In addition to examining library
reports, you should observe drive sled link LED and status LED activity.
The blinking codes described in
Note
Channel and SCSI drives in the UDS-2 drive sleds.
Figure 42 shows the locations of the status LEDs and the Fibre Channel link LED on the rear of a UDS-2
drive sled.
Figure 42 Rear View of Fibre Channel Drive Sled (UDS-2)
fibre port
FC link LED
SDLT-600 Fibre drives do not have a Fibre Channel link LED.
Note
354
Table 18 on page 355 are the same for Fibre
status LEDs:
- top = blue
- middle = amber
- bottom = green
Interpreting LED Codes
