14 Insert and tighten the two tall covers next to the drive clusters and the mid-module cover plate.
15 Install the grated covers on the side and top of the I/O management unit.
Scalar i2000 Installation Guide
tall top cover plate
mid-module cover plate
tall bottom cover plate
thumbscrews
thumbscrews
251
