Interpreting Drive Status
LEDs
Figure 3 Rear View of Fibre
Channel Drive Sled (UDS-2)
fibre port
FC link LED
Scalar i2000 User's Guide
The library reports all drive issues that can affect customer operations. In
2 addition to examining library reports, you should observe drive sled link
LED and status LED activity.
Note
Figure 3 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-2 drive sled.
Note
Chapter 2 Troubleshooting Your Library
The blinking codes described in
on page 133 are the same for Fibre Channel and
SCSI drives in the UDS-2 drive sleds.
status LEDs:
- top = blue
- middle = amber
- bottom = green
SDLT-600 Fibre drives do not have a Fibre Channel
link LED.
Interpreting LEDs
table 6 on page 58
