Figure 7 Locations - Colors
MCB FC / SCSI Port LEDs
MCB port LEDs
- left = green (belongs to
- right = green (belongs
Interpreting LBX
Terminator LEDs
Scalar i2000 User's Guide
SCSI port below)
to FC port above)
The LBX terminator has two versions. Version 01 has four LEDs and
Version 03 has six LEDs. For more information, see the Scalar i2000
2
Maintenance Guide.
LBX Terminator Version 01 LEDs
The LBX terminator has four green LEDs that indicate the presence of
modules in the library.
LEDs. Table 12 on page 67
LBX terminator.
Chapter 2 Troubleshooting Your Library
Figure 8 on page 67 shows the locations of the
describes how to interpret LED activity on the
Interpreting LEDs
2
66
