NEC UNIVERGE SV9100 Features And Specifications page 977

Conditions
With SV9100 software and GPZ-IPLE daughter board installed, half duplex connections are
not supported. For troubleshooting purposes, a managed switch capable of port mirroring is
required to capture packet data from the SV9100 IPLE Ethernet port.
When connecting via a dial up connection, a Dial Up Connection (PPP) must be configured
in Windows Network Connections.
When uploading via a Dial Up connection, uploading card configuration (Hardware Upload)
is not supported.
The hardware/software requirements for the host PC running the PCPro application are:
CPU
Memory
Operating System (OS)
Other
Communication Port
Disk Space
TCP Port
Screen Resolution
The hardware/software requirements for the host PC running WebPro are:
Browser
Network
Screen Resolution
You can have a maximum of four users logged into WebPro anytime.
You can have up to two phones in programming mode anytime.
You can have two WebPro users and two phone programming users logged in at the same
time for a total of four users in programming mode simultaneously. However, the two
phone programming users do not show up in session management in WebPro.
PCPro can be logged in with only one user. This is allowed only if no other users are
logged into programming mode (PCPro, WebPro, or Phone). Also, if a user is connected to
the switch via PCPro, no other user can log in through PCPro, WebPro, or Phone
Programming.
Item
Pentium
Pentium 4 2.5GHz (recommended)
128MB of RAM, 256MB (recommended)
Windows XP or Microsoft Vista
Windows 7 (32- and 64-bit)
Microsoft Internet Explorer 6.0 or higher
LAN, or Modem
35MB for PCPro (minimum)
TCP port 8000 must be open between the terminal
and the host PC for uploading/downloading via LAN.
PCPro/WebPro TCP port is set for 8000 at default,
but can be changed via WebPro using Program
90-38-02. Program 90-38-02 is not accessible from
Phone Programming or PCPro.
800 x 600 (minimum)
1024 x 760 (recommended)
Item
MS Internet Explorer 6.0 (or higher)
IP connection to the KTS
800 x 600 (minimum)
1024 x 760 (recommended)
977
Requirement
®
III 598MHz (minimum)
Requirement
