9.7.17.3

Programming example: Machining, counterspindle - without previous transfer

Programming steps
● Rear face
– Work offset
– ZV:
● Machining, counterspindle
Note
Special feature regarding "rear face":
The work offset that you choose in the parameter screen is only activated and not calculated.
This means that the workpiece zero for counterspindle machining should be stored in the
work offset. In addition, parameter ZV is not evaluated.
9.7.17.4

Programming example: Machining bar material

If you use bars to produce your workpieces, you can machine several workpieces on the
front and rear face by starting the program just once.
Programming steps - alternative 1:
● Program header specifying the work offset in which the workpiece zero is stored
● Machining, main spindle
● Complete transfer (withdraw blank: yes; cutting-off cycle: yes)
● Cutting-off
● Machining, counter-spindle
● End of program with number of workpieces to be machined
Programming steps - alternative 2:
● Start marker
● Machining, main spindle
● Complete transfer (withdraw blank: yes; cutting-off cycle: yes)
● Cutting-off
● Machining, counter-spindle
● Front face
● End marker
● Repeat from start to end marker
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Work offset is only activated
Parameter is not evaluated.
