When Using Floor Jack
WARNING
!
If the vehicle to be jacked up only at the front
or rear end, be sure to block the wheels on
ground in order to ensure safety.
After the vehicle is jacked up, be sure to
support it on stands. It is extremely
dangerous to do any work on the vehicle
raised on jack alone.
CAUTION
!
• Never apply jack against rear suspension
parts (i.e., stabilizer, etc.) or vehicle floor,
or it may get deformed.
• When jacking up the front end, be sure to
use an air type floor jack with the following
specified height or a manual type floor jack
of the following size. Otherwise, the jack
may cause the bumper or vehicle body
panel a damage.
Jack size
Height "h": under 145 mm (under 5.71 in.)
Length "l": above 900 mm (above 35.4 in.)
"l"
"h"
I4RS0A010002-01
In raising front or rear vehicle end off the floor by jacking,
be sure to put the jack against front suspension frame
(1) or rear jacking bracket (2).
1
To perform service with either front or rear vehicle end
jacked up, be sure to place safety stands (1) under body
mounting stay (2) so that vehicle body is securely
supported. And then check to ensure that body mounting
stay (2) does not slide on safety stands (1) and the
vehicle is held stable for safety's sake.
[A]
2
[B]
[A]: Front
General Information:
2
I4RS0A010003-01
1
2
1
I4RS0A010004-01
[B]: Rear
0A-6
