CHAPTER 24 ADDRESS MATCH DETECTION FUNCTION

24.1 Overview of Address Match Detection Function

If the address of the instruction to be processed next to the instruction currently
processed by the program matches the address set in the detect address setting
registers, the address match detection function forcibly replaces the next instruction
to be processed by the program with the INT9 instruction to branch to the interrupt
processing program. Since the address match detection function can use the INT9
interrupt for instruction processing, the program can be corrected by patch
processing.
I Overview of Address Match Detection Function
• The address of the instruction to be processed next to the instruction currently processed by
the program is always held in the address latch through the internal bus. The address match
detection function always compares the value of the address held in the address latch with
that of the address set in the detect address setting registers. When these compared values
match, the next instruction to be processed by the CPU is forcibly replaced by the INT9
instruction, and the interrupt processing program is executed.
• There are two detect address setting registers (PADR0 and PADR1), each of which has an
interrupt enable bit. The generation of an interrupt due to a match between the address held
in the address latch and the address set in the detect address setting registers can be
enabled and disabled for each register.
