Goodrive350 IP55 High-ingress Protection Series VFD
Function
code
Reference object of B
P00.08
frequency command
Combination mode of setting
P00.09
Function selection of
P05.01– multifunction digital input
P05.06 terminals (S1–S4, HDIA,
P08.42
P08.43
UP/DOWN terminal control
P08.44
Name
source
HDIB)
Reserved
Reserved
setting
Description
5: Simple PLC program
6: Multi-step speed running
7: PID control
8: Modbus/Modbus TCP communication
9: PROFIBUS/CANopen/DeviceNet
communication
10: Ethernet communication
11: High-speed pulse HDIB
12: Pulse train AB
13: EtherCAT/PROFINET/ EtherNet IP
communication
14: Programmable expansion card
15: Reserved
0: Max. output frequency
1: A frequency command
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting
and A setting
15: Switch between combination setting
and B setting
/
/
0x000–0x221
Ones place: Frequency setting selection
0: The setting made through UP/DOWN is
valid.
1: The setting made through UP/DOWN is
invalid.
-74-
Basic operation guidelines
Default
0
0
See
"Group
P05––
Input
terminal
functions"
/
/
0x000
