Function
Name
code
P01.23 Start delay
P01.24 Stop speed delay 0.0–600.0s
Open-loop 0Hz
P01.25
output selection
DEC time for
P01.26
emergency stop
Time of starting
P01.27 segment of DEC S
curve
Time of ending
P01.28 segment of DEC S
curve
Short-circuit
P01.29
braking current
Hold time of
P01.30 short-circuit braking
for start
Hold time of
P01.31 short-circuit braking
for stop
Pre-exciting time
P01.32
for jogging
Starting frequency
P01.33 of braking for stop
in jogging
P01.34 Sleep delay
Description
Setting range: 0.0–3600.0s (valid only when
P01.21 = 1)
After a VFD running command is given, the
VFD restarts running output with the delay
defined by P01.23 from the standby state, to
implement brake release.
Setting range: 0.0–600.0s
0: Output without voltage
1: Output with voltage
2: Output with the DC braking current for stop
0.0–60.0s
0.0–50.0s
0.0–50.0s
When the VFD starts in direct start mode
(P01.00 = 0), set P01.30
enter short-circuit braking.
During stop, if the running frequency of VFD is
lower than the starting frequency of brake for
stop (P01.09), set P01.31
to enter short-circuit braking for stop, and then
carry out DC braking in the time specified by
P01.12. (See descriptions for P01.09–P01.12.)
P01.29 setting range: 0.0–150.0% (of the rated
VFD output current)
Setting range of P01.30: 0.0–50.0s
Setting range of P01.31: 0.0–50.0s
0.000s–10.000s
0.00Hz–P00.03
0.0s–3600.0s
-135-
to a non-zero value to
to a non-zero value
Function parameter list
Default Modify
○
0.0s
○
0.0s
○
0
○
2.0s
◎
0.1s
◎
0.1s
○
0.0%
○
0.00s
○
0.00s
○
0.300s
○
0.00Hz
○
0.0s
