Goodrive350 IP55 High-ingress Protection Series VFD

The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.

For the selection of accessories with different material requirements than those listed
above, please refer to the low-voltage VFD GDL series filter option brochure.
D.7 EMC filter
The product is shipped with J10 jumper pre-installed.
Note: Disconnect J10 in the following situations:

The EMC filter is applicable to the neutral-grounded grid system. If it is used for the IT
grid system (that is, non-neutral grounded grid system), disconnect J10.

If leakage protection occurs during configuration of a residual-current circuit breaker,
disconnect J10.
Note: Do not connect C3 filters in IT power systems.
Field identifier
A FLT: EMC filter series
Figure D-5 Filter model
-
FLT P 04
A B
Table D-8 Model description
-
045 L
C D E
Description
-389-
Optional peripheral accessories
J10
B
F
