Goodrive350 IP55 High-ingress Protection Series VFD
Indicator Definition
LED2 Power indicator
LED3 Status indicator
EC-PG502 terminal function:
Signal
PWR
GND
A1+
A1-
B1+
B1-
R1+
R1-
C1+
C1-
D1+
D1-
A2+
A2-
B2+
B2-
Z2+
Z2-
AO+
AO-
BO+
BO-
ZO+
ZO-
indicator Blinking: C1 or D1 of the encoder is disconnected.
On: Encoder signals are normal.
This indicator is on after the control board feeds power to the PG
card.
On: The expansion card is connecting with the control board.
Blinking periodically (the period is 1s, on for 0.5s, and off for the
other 0.5s): The expansion card is properly connected to the
control board.
Off: The expansion card is disconnected from the control board.
Description
Voltage: 5V ± 5%
Encoder power
Max. output current: 150mA


Encoder interface


Pulse reference



Frequency-divide
d output
Function
Description
Supporting Sin/Cos encoders
SINA/SINB/SINC/SIND 0.6–1.2Vpp; SINR 0.2–0.85Vpp
Max. frequency response of A/B signals: 200 kHz
Max. frequency response of C/D signals: 1 kHz
Supporting 5V differential signal
Response frequency: 200 kHz
Differential output of 5 V
Supporting frequency division of 1–255, which can be
set through P20.16 or P24.16 Max. output frequency:
200 kHz
-347-
Expansion card
