INVT Goodrive350 Series Operation Manual page 170

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Integral coefficient
P04.43
in IF mode for AM 1
Starting frequency
point for switching
P04.44
off IF mode for AM
Enabling IF mode
P04.45
for AM 2
Current setting in IF
P04.46
mode for AM 2
Proportional
coefficient in IF
P04.47
mode for AM 2
Integral coefficient
P04.48
in IF mode for AM 2
Starting frequency
point for switching
P04.49
off IF mode for AM
End frequency
point for switching
P04.50
off IF mode for AM
End frequency
point for switching
P04.51
off IF mode for AM
control.
Setting range: 0–5000
When IF control is adopted for AM 1, the
function code is used to set the integral
coefficient of the output current closed-loop
control.
Setting range: 0–5000
0.00–P04.50
1
0: Disable
1: Enable
When IF control is adopted for AM 2, the
function code is used to set the output current.
The value is a percentage in relative to the
rated current of the motor.
Setting range: 0.0–200.0%
When IF control is adopted for AM 2, the
function code is used to set the proportional
coefficient of output current closed-loop control.
Setting range: 0–5000
When IF control is adopted for AM 2, the
function code is used to set the integral
coefficient of output current closed-loop control.
Setting range: 0–5000
0.00–P04.51
2
P04.44–P00.03
1
P04.49–P00.03
2
Description
-152-
Function parameter list
Default Modify
○
150
○
10.00Hz
◎
0
○
120.0%
○
350
○
150
○
10.00Hz
○
25.00Hz
○
25.00Hz
