INVT Goodrive350 Series Operation Manual page 213

Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
Fault severity group
P11.31
Fault severity group
P11.32
Fault severity group
P11.33
Fault severity group
P11.34
Fault severity group
P11.35
Fault severity group
P11.36
Fault severity group
P11.37
Fault severity group
P11.38
Fault severity group
P11.39
Fault severity group
P11.40
Fault severity group
P11.41
Fault severity group
P11.42
Fault severity group
P11.43
Fault severity group
P11.44
Fault severity group
P11.45
Fault severity group
P11.46
Fault severity group
P11.47
Fault severity group
P11.48
0x0000–0x3333
1
Thousands
place/ones place:
2
0: Report a fault
1: Report a fault after deceleration to stop
3
2: Pre-alarm,
according to P11.51
4
3: Screen out fault
Note: Different fault actions are taken for
5 different fault severities.
The first 10 faults are not grouped by severity,
but each four of the subsequent faults are
6
grouped by severity in ascending order from
right to left in hexadecimal format, that is, from
7
the ones place to the thousands place (for
example, the ones place of fault severity group
8
1 corresponds to fault 11).
Group 1: Faults 11–14 (OL1, OL2, SPI, SPO)
9
Group 2: Faults 15–18 (OH1, OH2, EF, CE)
Group 3: Faults 19–22 (ItE, tE, EEP, PIDE)
10
Group 4: Faults 23–26 (bCE, END, OL3, PCE)
Group 5: Faults 27–30 (UPE, DNE, E-DP,
11
E-NET)
Group 6: Faults 31–34 (E-CAN, ETH1, ETH2,
12
dEu)
Group 7: Faults 35–38 (STo, LL, ENC1o,
13 ENC1d)
Group 8: Faults 39–42 (ENC1Z, STO, STL1,
STL2)
14
Group 9: Faults 43–46 (STL3, CrCE, P-E1,
P-E2)
15
Group 10: Faults 47–50 (P-E3, P-E4, P-E5,
P-E6)
16
Group 11: Faults 51–54 (P-E7, P-E8, P-E9,
P-E10)
17
Group 12: Faults 55–58 (E-Err, ENCU, E-PN,
SECAN)
18
Description
place/hundreds
with the action
-195-
Function parameter list
Default Modify
0x0000
place/tens
0x0000
0x0000
executed
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
