Goodrive350 IP55 High-ingress Protection Series VFD
Expansion card installation procedure:
STEP1
Unscrew the screw, take out the
keypad, and remove the upper
cover.
STEP3
Tighten the screws.
STEP5
Assemble the upper and lower
covers.
STEP7
Figure A-2 Expansion card installation procedure
Align the EC positioning holes a nd
positioning studs to fix the EC.
Unscrew the screw and remove the lower
cover.
EC cable tie line
Outlet
-328-
Expansion card
STEP2
Insert the EC.
STEP4
STEP6
