INVT Goodrive350 Series Operation Manual page 48

Goodrive350 IP55 High-ingress Protection Series VFD
The following figure shows how to enter or exit different menus step by step.
16:02:35 Fwd Local Ready
Set Freq
50.00
P17.00 Hz
DC bus voltage
540.0
P17.11 V
DigiInputTrmlState
000000
P17.12
Parameter About
Figure 5-9 Enter/exit menu diagram 2
GD350 16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Menu Back
16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Back
16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Back
16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Back
16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Back
16:02:35
Parameter groups
User defined parameters
State monitoring
Motor parameter autotune
Copy parameter/Restore default
System settings
Back
Fwd Local Ready GD350
Home Sele
Fwd Local Ready GD350
Home Sele
Fwd
Local Ready
GD350
Home Sele
Fwd GD350
Local Ready
Home Sele
Fwd Local Ready GD350
Home Sele
Fwd Local Ready
GD350
Home Sele
-30-
Basic operation guidelines
16:02:35 Fwd Local Ready GD350
Basic parameters
Motor and encoder parameters
Factory parameters
Terminal function parameters
Optional card parameters
Factory customized parameters
Back Edit Sele
16:02:35 Fwd Local Ready GD350
P00.00: Speed Ctrl Run Cmd
P00.01: Run Cmd Channel
P00.02: Comm Cmd Channel
P00.03: Max Output Freq
P00.04: RunFreq Up Limit
P00.05: RunFreq Low Limit
Back Edit Sele
16:02:35
Fwd Local Ready GD350
State monitoring parameters
Fault types
Fault recording parameters
Clear fault records
Modified parameters
Customize Home parameters
Back Home Sele
16:02:35 Fwd Local Ready
GD350
Ensure motor nameplate parameters are set
correctly.
Back Home OK
Fwd
16:02:35 Local Ready
GD350
MemArea
1: BACKUP01
MemArea
2: BACKUP02
MemArea 3: BACKUP03
Restore default (excl motor para)
Restore default (test mode)
Restore default (incl motor para)
Back Edit Sele
16:02:35
Fwd Local Ready GD350
Language
Time/date
Backlight brightness
Backlight time
Enable power-on setup wizard
Power-on setup wizard
Back Home Sele
