Goodrive350 IP55 High-ingress Protection Series VFD
Setting Function
69 Decrease pulses
70 Electronic gear selection
71 Switch to the master
72 Switch to the slave
73 Rolling diameter reset
Winding/unwinding
74
switchover
75 Tension control pre-driving
Disabling roll diameter
76
calculation
77 Clearing alarm display
Manual braking in tension
78
Triggering a forcible
79 material feeding interrupt
Initial roll diameter
80
selection 1
Initial roll diameter
81
selection 2
82 Triggering fire control
PID switchover in tension
83
84–95 Reserved
If the terminal is valid when the function is selected, the
pulse input is decreased according to P21.27 (Pulse
superposition speed).
If the terminal is valid when the function is selected, the
proportional numerator is switched to P21.30 (Numerator of
the 2nd command ratio).
When the function is enabled in stopped state, the unit
switches to the master mode.
When the function is enabled in stopped state, the unit
switches to the slave mode.
If the terminal is valid when the tension-specific function is
used, the terminal resets the roll diameter.
If the terminal is valid when the tension-specific function is
used, the terminal switches between the winding mode and
unwinding mode.
If the terminal is valid when the tension-specific function is
used, the VFD performs tension control pre-driving.
If the terminal is valid when the tension-specific function is
used and the terminal is valid, the VFD does not calculate
the roll diameter.
If the terminal is valid when the tension-specific function is
used, tension alarm display is cleared.
If the terminal is valid when the tension-specific function is
control used, manual braking is allowed.
If the terminal is valid when the tension-specific function is
used, the VFD triggers a forcible material feeding interrupt
signal signal.
If the terminal is valid when the tension-specific function is
used, initial roll diameters 2 and 2 are combined for different
initial roll diameter selection.
If the terminal is valid when the tension-specific function is
used, initial roll diameters 1 and 2 are combined for different
initial roll diameter selection.
If the terminal is valid when the fire mode is enabled, the
VFD triggers a fire control signal.
If the terminal is valid when the tension-specific function is
used, the terminal switches from the first group of PID
control parameter to the second group. The first group is the default
PID parameter group.
/
Description
-87-
Basic operation guidelines
