INVT Goodrive350 Series Operation Manual page 87

Goodrive350 IP55 High-ingress Protection Series VFD
Function
code
Hold time of starting
P01.02
P01.03 Braking current before start 0.0–100.0%
DC braking time before
P01.04
P01.05 ACC and DEC mode
P01.08
Starting frequency of
P01.09
braking for stop
Wait time before DC
P01.10
braking for stop
P01.11 DC braking current for stop 0.0–100.0%
P01.12 DC braking time for stop 0.00–50.00s
FWD/REV run deadzone
P01.13
FWD/REV run switching
P01.14
P01.15
Stop speed detection
P01.16
Terminal-based running
P01.18 command protection at
Action selected when
running frequency less
P01.19 than frequency lower limit
(valid when frequency
lower limit greater than 0)
Name
frequency
start
Stop mode
time
mode
Stop speed
mode
power-on
Description
0.0–50.0s
0.00–50.00s
0: Linear
1: S curve
Note: If mode 1 is selected, set P01.06,
P01.07, P01.27 and P01.08 accordingly.
0: Decelerate to stop
1: Coast to stop
0.00Hz–P00.03 (Max. output frequency)
0.00–50.00s
0.0–3600.0s
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0.00–100.00Hz
0: Detect by the set speed (unique in space
voltage vector control mode)
1: Detect according to speed feedback
0: The terminal running command is invalid at
power-on
1: The terminal running command is valid at
power-on
Setting range: 0x00–0x12
Ones place: Action selection
0: Run at the frequency lower limit
1: Stop
2: Sleep
Tens place: Stop mode
-69-
Basic operation guidelines
Default
0.0s
0.0%
0.00s
0
0
0.00Hz
0.00s
0.0%
0.00s
0.0s
1
0.50 Hz
1
0
0x00
