Goodrive350 IP55 High-ingress Protection Series VFD
Function
Name
code
AO2 output upper
P26.40
limit
AO2 output
P26.41 corresponding to
upper limit
AO2 output filter
P26.42
time
AO3 output lower
P26.43
limit
AO3 output
P26.44 corresponding to
lower limit
AO3 output upper
P26.45
limit
AO3 output
corresponding to
P26.46
upper limit
AO3 output filter
P26.47
time
P26.48–
Reserved
P26.52
Group P27––Programmable expansion card functions
Function
Name
code
Enabling
P27.00
programmable card
P27.01 I_WrP1
P27.02 I_WrP2
Description
limit.
When the analog output is current output, 1mA
equals 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
10V (20mA)
AO
0.0%
Setting range of P26.38:
Setting range of P26.39: 0.00V–10.00V
Setting range of P26.40: P26.38–300.0%
Setting range of P26.41: 0.00V–10.00V
Setting range of P26.42: 0.000s–10.000s
Setting range of P26.43:
Setting range of P26.44: 0.00V–10.00V
Setting range of P26.45: P26.43–300.0%
Setting range of P26.46: 0.00V–10.00V
Setting range of P26.47: 0.000s–10.000s
-
Description
0–1
The function code is used to enable the
programmable card function. This function is
reserved.
0–65535
The function code is used for the VFD to write
a value to WrP1 of the programmable card.
0–65535
The function code is used for the VFD to write
a value to WrP2 of the programmable card.
-248-
100.0%
-300.0%–P26.40
-300.0%–P26.45
Function parameter list
Default Modify
○
100.0%
○
10.00V
○
0.000s
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
- -
Default Modify
◎
0
○
0
○
0
